The actuators for proportional valves type F MM E + F HT P are designed according to the modular principle and consist of a solenoid body with explosion protection according to ATEX / IECEx type F MM E and a tube type F HT P. The data sheet shows the construction method and exemplary technical data on the basis of exemplary designs. The grading of the sizes is adapted to the actuation of valves of nominal sizes NG4, NG6 and NG10.

The solenoid body is fixed on the tube by means of a fixing nut and can be removed or replaced without opening the hydraulic circuit

Sizes (Ø): 37 mm, 45 mm, 63 mm
Nominal working pressure: 210 / 250 bar
Overall stroke: 4 mm - 8 mm
Working stroke: 2 mm – 4 mm
Rated magnetic force: 39 N – 120 N

• Considerable proportionality between force and current

• Small hysteresis through precise bearing of the armature

• Horizontal magnetic force vs. stroke characteristic within control range

• Push type

• Manual override

• Electrical connection via terminal box

• Fastening via central thread

• Protection class: IP65

• Voltage type: direct current, DC

• Options: Protection class IP67, AC-version with rectifier
